MSI PRO X870-P WIFI AM5 ATX specs

  Motherboards Specs >> MSI >> MSI PRO X870-P WIFI AM5 ATX
Specifications | Reviews


MSI PRO X870-P WIFI AM5 ATX



General Specs MSI PRO X870-P WIFI AM5 ATX Motherboard

Chipset:
AMD X870
CPU Socket:
AM5
Memory Slots:
4x 288-Pin
Memory Support:
DDR5 2400, 3200, 4200, 4700, 4800, 5600, 6400, 8200 MT/s
Storage Slots:
1x M.2 (M Key) 2260, 2280 (PCIe 5.0 x4)
1x M.2 (M Key) 2280, 22110 (PCIe 4.0 x4)
1x M.2 (M Key) 2260, 2280 (PCIe 4.0 x2)
Expansion Slots:
1x PCIe 5.0 x16
1x PCIe 4.0 x16 (x4 mode)
2x PCIe 3.0 x16 (x1 mode)
Wi-Fi:
Wi-Fi 7 (802.11be); Tri-Band (2.4, 5, & 6 GHz) with MU-MIMO Support
Form Factor:
ATX

CPU MSI PRO X870-P WIFI AM5 ATX Motherboard

Chipset:
AMD X870
CPU Socket:
AM5

Back Panel I/O MSI PRO X870-P WIFI AM5 ATX Motherboard

USB:?Universal Serial Bus
1x USB-C (USB4)
1x USB-C (USB 3.2 Gen 2x2)
2x USB-A (USB 3.1/3.2 Gen 2)
2x USB-A (USB 3.0 / 3.1/3.2 Gen 1)
4x USB-A (USB 2.0)
Thunderbolt:
No
Display:
1x HDMI 2.1
Audio:
3x 1/8" / 3.5 mm
Ethernet / Controller:
1x Realtek 8126VB 5GbE
Wi-Fi Antenna:
2x Connector
Buttons:
BIOS Flashback, Clear CMOS

Memory MSI PRO X870-P WIFI AM5 ATX Motherboard

Memory Slots:
4x 288-Pin
Memory Support:
DDR5 2400, 3200, 4200, 4700, 4800, 5600, 6400, 8200 MT/s
Maximum Capacity:
256 GB
Channel Architecture:
Dual Channel
ECC Support:
Non-ECC Buffered

Storage Expansion MSI PRO X870-P WIFI AM5 ATX Motherboard

SATA:?Serial Advanced Technology Attachment
No
Storage Slots:
1x M.2 (M Key) 2260, 2280 (PCIe 5.0 x4)
1x M.2 (M Key) 2280, 22110 (PCIe 4.0 x4)
1x M.2 (M Key) 2260, 2280 (PCIe 4.0 x2)
Optane Memory Support:
No
RAID Support:
RAID 0, 1

Internal I/O MSI PRO X870-P WIFI AM5 ATX Motherboard

Expansion Slots:
1x PCIe 5.0 x16
1x PCIe 4.0 x16 (x4 mode)
2x PCIe 3.0 x16 (x1 mode)
USB:?Universal Serial Bus
1x USB 3.1/3.2 Gen 2 Header (Supports 1 USB-C Port)
1x USB 3.0 / 3.1/3.2 Gen 1 Header (Supports 2 USB-A Port)
2x USB 2.0 Header (Supports 4 USB-A Port)
Air Cooling:
1x 4-Pin CPU
6x 4-Pin System
Liquid Cooling:
1x 4-Pin Pump
Power Connectors:
1x 24-Pin Mainboard
2x 8-Pin CPU
1x 8-Pin ATX
Security:
Chassis Intrusion, TPM Header
LED Header:
4x RGB
Audio:
1x Speaker
Diagnostics:
2-Digit Debug LED, Flash BIOS
Add-On:
2x Thunderbolt Card Header
1x Tuning Controller

BIOS MSI PRO X870-P WIFI AM5 ATX Motherboard

ROM:
256 Mb

Front Panel I/O MSI PRO X870-P WIFI AM5 ATX Motherboard

Front Panel I/O:
AAFP, USB 3.0 / 3.1/3.2 Gen 1, USB 3.1/3.2 Gen 2

Audio MSI PRO X870-P WIFI AM5 ATX Motherboard

Audio Codec:
Realtek ALC897 (7.1-Channel)
DAC:
No

Wireless MSI PRO X870-P WIFI AM5 ATX Motherboard

Wi-Fi:
Wi-Fi 7 (802.11be); Tri-Band (2.4, 5, & 6 GHz) with MU-MIMO Support
Bluetooth:
5.4
Module Support:
1 E Key M.2

Software MSI PRO X870-P WIFI AM5 ATX Motherboard

OS Compatibility:
Windows 11 (64-Bit Only)

Physical MSI PRO X870-P WIFI AM5 ATX Motherboard

Form Factor:
ATX
Dimensions:
12.0 x 9.60" / 304.8 x 243.84 mm
