DFI K8T800Pro-ALF specs
Motherboards Specs >> DFI >> DFI K8T800Pro-ALF| Specifications | | | Reviews |
Processor DFI K8T800Pro-ALF
Socket:
S754
Processors supported:
AMD Athlon 64
System bus:
HyperTransport
Chipset DFI K8T800Pro-ALF
Chipset:
VIA K8T800 Pro
BIOS:
Award with the opportunity of a disaster recovery
SLI/CrossFire:
Scalable Link Interface
Scalable Link Interfaceno
Memory DFI K8T800Pro-ALF
Memory:
DDR DIMM, 266 - 400 MHz
Number of memory slots:
2
Maximum memory:
2 GB
Disk controllers DFI K8T800Pro-ALF
IDE:Integrated Drive Electronics
Integrated Drive Electronicsnumber of slots: 2, UltraDMA 133
SATA:Serial Advanced Technology Attachment
Serial Advanced Technology Attachmentnumber of connectors SATA 1.5Gb/s: 2, RAID: 0, 1, JBOD
Expansion slots DFI K8T800Pro-ALF
Expansion slots:
AGP, 6xPCI
Audio/video DFI K8T800Pro-ALF
Sound:
5.1CH, AC'97
Network DFI K8T800Pro-ALF
Ethernet:
10/100 Mbit/s, based on the VIA K8T800
Connection DFI K8T800Pro-ALF
Interfaces:
8 USB, 2xFireWire (IEEE1394a), S/PDIF output, S/PDIF, 2xCOM, Ethernet, PS/2 (keyboard), PS/2 (mouse), LPT
Back panel connectors:
, Ethernet, PS/2 (keyboard), PS/2 (mouse), LPT
Advanced settings DFI K8T800Pro-ALF
Form factor:
ATX
Packing list:
2 Serial ATA cable, 1 cable 2-port SATA power, 1 module COM port, 2 module 2-port USB2.0, 2 cable UltraDMA 133/100/66, 1 cable IDE 1 FDD cable
Additional information:
Control of opening of the housing. 20 pin ATX + 4 pin 12V power connectors. Device status monitoring.
