Gigabyte P650G 650W 80 PLUS Gold GP-P650G-US specs.
Power Supplies Specs >> GIGABYTE >> Gigabyte P650G 650W 80 PLUS Gold GP-P650G-US| Specifications | | | Reviews |
Connectivity Gigabyte P650G 650W 80 PLUS Gold GP-P650G-US
Total Connectors:
1 x 20+4-Pin ATX Motherboard
1 x 4+4-Pin EPS CPU
4 x 6+2-Pin PCIe
6 x 15-Pin SATA
3 x 4-Pin Peripheral / Molex
1 x 4-Pin Floppy
1 x 4+4-Pin EPS CPU
4 x 6+2-Pin PCIe
6 x 15-Pin SATA
3 x 4-Pin Peripheral / Molex
1 x 4-Pin Floppy
Cable Design:
Flat
PCIe Connector Distances:
19.7" / 500 mm
5.9" / 150 mm
5.9" / 150 mm
SATA Connector Distances:
19.7" / 500 mm
5.9" / 150 mm
5.9" / 150 mm
Peripheral Connector Distances:
5.9" / 150 mm
Floppy Connector Distances:
5.9" / 150 mm
ATX Connector Distance:
23.6" / 600 mm
EPS Connector Distances:
23.6" / 600 mm
Electrical Gigabyte P650G 650W 80 PLUS Gold GP-P650G-US
Total Wattage:
650 W
Number of +12 V Rails:
1
Combined Power for +12 V:
650 W
Max Load for +12 V:
54.2 A
Combined Power for +3.3/+5 V:
120 W
Max Load for +3.3 V:
20 A
Max Load for +5 V:
20 A
Max Power for +5 Vsb:
12.5 W
Max Load for +5 Vsb:
2.5 A
Max Power for -12 V:
3.6 W
Max Load for -12 V:
0.3 A
AC Input Power:
100 to 240 VAC, 50 / 60 Hz at 6 to 12 A
General Gigabyte P650G 650W 80 PLUS Gold GP-P650G-US
Efficiency Rating:
80 PLUS Gold
Active Power Factor Correction:
Yes
Efficiency:
90%
Hold up Time:
16 ms
Power-Good Signal:
100 to 500 ms
Cooling Gigabyte P650G 650W 80 PLUS Gold GP-P650G-US
Fan Size:
120 mm
Bearing Type:
Hydraulic
Physical Gigabyte P650G 650W 80 PLUS Gold GP-P650G-US
Form Factor:
ATX
Compliance:
ATX 12 V v2.31
Protection:
Over-Current Protection, Over-Power Protection, Over-Temperature Protection, Over-Voltage Protection, Short-Circuit Protection, Under-Voltage Protection
Certifications:
FCC
Mean Time Between Failures (MTBF):
100,000 Hours
Dimensions:
5.9 x 3.4 x 5.5" / 150 x 86 x 140 mm
