Technical Characteristics MGE Comet S31 20 kVA
Type:
double conversion
Output power:
20000 VA/16000 Tues
Time at full load:
10 min
Output Waveform:
sinusoid
The number of output power connectors:
1 (one with a battery - 1)
Type of output power connectors:
IEC 320 C13 (computer)
Efficiency:
93%
Nonlinear distortion factor:
4%
Input/Output MGE Comet S31 20 kVA
At the inlet:
3-phase power
At the exit:
1-phase power supply
Input voltage:
325 - 445V
Input Frequency:
47 - 63 Hz
Output frequency:
49 - 61 Hz
Crest factor:
5:
1
Management MGE Comet S31 20 kVA
Slot for optional interfaces:
Yes
Functionality MGE Comet S31 20 kVA
Information Display:
LEDs
Manual By-pass:
Yes
Automatic By-pass:
Yes
Battery MGE Comet S31 20 kVA
The possibility of replacing batteries:
Yes
Hot-swappable batteries:
Yes
Protection MGE Comet S31 20 kVA
Overload protection:
Yes
Protection from high-voltage pulses:
Yes
Noise filtering:
Yes
Short-circuit protection:
Yes
Additional Information MGE Comet S31 20 kVA
Noise level:
50 dV
Color:
white
Dimensions (WxHxD):
560x1085x680 mm
Weight:
450 kg
Features:
SUB-D port 15 to connect to the LAN; USB, RS-232, Dry Contact, support SNMP - optional via board
