APC Symmetra PX 96kW Scalable to 160kW, 400V specs.
Uninterruptible Power Supplies Specs >> APC >> APC Symmetra PX 96kW Scalable to 160kW, 400V| Specifications | | | Reviews |
Technical Characteristics APC Symmetra PX 96kW Scalable to 160kW, 400V
Type:
double conversion
Output power:
96,000 VA/96000 Tues
Output Waveform:
sinusoid
The number of output power connectors:
1 (one with a battery - 1)
Rackable:
Yes
Efficiency:
95%
Nonlinear distortion factor:
2%
Input/Output APC Symmetra PX 96kW Scalable to 160kW, 400V
At the inlet:
3-phase power
At the exit:
1-faznoe/3-faznoe voltage
Input voltage:
340 - 477 V
Input Frequency:
40 - 70 Hz
Output voltage (battery mode):
± 3%
Management APC Symmetra PX 96kW Scalable to 160kW, 400V
Interfaces:
Ethernet 10/100
Slot for optional interfaces:
Yes
Dry contacts:
Yes
Functionality APC Symmetra PX 96kW Scalable to 160kW, 400V
Information Display:
LEDs
Audible alarm:
Yes
Cold start:
Yes
Manual By-pass:
Yes
Automatic By-pass:
Yes
Battery APC Symmetra PX 96kW Scalable to 160kW, 400V
Charging time:
2:00
The possibility of replacing batteries:
Yes
Hot-swappable batteries:
Yes
Connection of additional battery:
Yes
Protection APC Symmetra PX 96kW Scalable to 160kW, 400V
Overload protection:
Yes
Protection from high-voltage pulses:
Yes
Noise filtering:
Yes
Additional Information APC Symmetra PX 96kW Scalable to 160kW, 400V
Noise level:
63 dV
Color:
black
Dimensions (WxHxD):
1200x1991x1070 mm
Height (in units):
42 U
Weight:
1748 kg
Features:
Configurable maximum output power 160000Vt/160000VA, 1 or 3-phase output voltage, support SNMP - optional and there is no internal battery - uses external battery system
