Technical Characteristics APC Symmetra PX 32kW Scalable to 160kW, 400V w/ Integrated Modular Distribution
Type:
double conversion
Output power:
VA 32000/32000 Tues
Time at full load:
6 min
Time at half load:
19.6 min
Output Waveform:
sinusoid
The number of output power connectors:
1 (one with a battery - 1)
Type of output power connectors:
IEC 320 C13 (computer)
Rackable:
Yes
Efficiency:
94%
Nonlinear distortion factor:
5%
Input/Output APC Symmetra PX 32kW Scalable to 160kW, 400V w/ Integrated Modular Distribution
At the inlet:
3-phase power
Input voltage:
340 - 477 V
Input Frequency:
45 - 65 Hz
Output voltage (battery mode):
± 3%
Output frequency:
47 - 53 Hz
Management APC Symmetra PX 32kW Scalable to 160kW, 400V w/ Integrated Modular Distribution
Interfaces:
Ethernet 10/100
Slot for optional interfaces:
Yes
Dry contacts:
Yes
Functionality APC Symmetra PX 32kW Scalable to 160kW, 400V w/ Integrated Modular Distribution
Information Display:
LCD Screen
Audible alarm:
Yes
Automatic By-pass:
Yes
Battery APC Symmetra PX 32kW Scalable to 160kW, 400V w/ Integrated Modular Distribution
Charging time:
3.5 hour
The possibility of replacing batteries:
Yes
Hot-swappable batteries:
Yes
Connection of additional battery:
Yes
Protection APC Symmetra PX 32kW Scalable to 160kW, 400V w/ Integrated Modular Distribution
Overload protection:
Yes
Protection from high-voltage pulses:
Yes
Noise filtering:
Yes
Additional Information APC Symmetra PX 32kW Scalable to 160kW, 400V w/ Integrated Modular Distribution
Noise level:
61 dV
Color:
black
Dimensions (WxHxD):
1200x1991x1070 mm
Height (in units):
42 U
Weight:
664 kg
Features:
Configurable maximum output power 160000Vt/160000VA, 1 or 3-phase output voltage, support SNMP - optional and there is no internal battery - uses external battery system
