LinkWorld LW2-500W specs.
Power Supplies Specs >> LinkWorld >> LinkWorld LW2-500W| Specifications | | | Reviews |
General characteristics LinkWorld LW2-500W
Power:
500 W
Cooling system:
2 fan (80 mm + 80 mm)
Connectors LinkWorld LW2-500W
Type of connector for the motherboard:
20+4 pin
Number of connectors 4-pin CPU:
1
Number of connectors 15-pin SATA:
2
Number of connectors 4-pin IDE:
4
Number of connectors 4-pin Floppy:
1
Current strength LinkWorld LW2-500W
Current for the +3.3 V:
28 A
Current on The +5 V:
38 A
The current on the +12V line 1:
20 A
Current line -12:
0.8 A
Current on The +5 V Standby:
2 A
Additional information LinkWorld LW2-500W
Overvoltage protection:
Yes
Short circuit protection:
Yes
Dimensions (HxWxD):
86x150x140 mm
