How to flash Philips Xenium S566?
Why reinstall the firmware?
Errors begin to appear in the Android operating system.
Some applications do not open, reinstalling which does not lead to a positive result.
Many programs from the Play Market do not work.
The phone turns off for no apparent reason.
The phone began to work slowly.
You are not satisfied with the functionality of the stock firmware.
Where can I find the firmware?
On the website of your phone manufacturer.
On sites where third-party developers post custom operating systems.
What should be done before installing the firmware?
Back up your contacts and user data and transfer it to your computer.
Insert SD card. An SD card is needed to write firmware to it.
Find out the exact model of your smartphone.
Fully charge your device.
Download archive with Firmware. Place it on the SD card.
Installing TWRP Recovery
Download the Official TWRP App to your phone from the Play Market. And install this app.
When you start the application for the first time, you must agree to install a new firmware and all the risks associated with this, as well as agree to grant the application Superuser rights and click the 'OK' button.
On the next screen, you need to select the 'TWRP FLASH' item and give the application root-rights.
On the main screen of the application, the 'Select Device' drop-down list is available, in which you need to find and select the device model for installing the recovery.
After selecting a phone, the application will direct the user to a web page to download the modified recovery environment image file. Download the proposed *.img file.
When the download is finished, you need to return to the main screen of the Official TWRP App and click on the 'Select a file to flash' button. Select the file downloaded in the previous step.
Press the 'FLASH TO RECOVERY' button and confirm your choice, press 'OK'.
When the message 'Flash Completed Succsessfuly!' appears on the screen. Click the 'OK' button. The TWRP installation procedure is now complete.
Transfer the necessary files to the SD memory card. Using a PC or laptop card reader, it will be much faster.
Insert a SD memory card into the phone.
To reboot in recovery, it is convenient to use a special item in the Official TWRP App menu, accessible by pressing the button with three stripes in the upper left corner of the main screen of the application. We open the menu, select the 'Reboot' item, and then tap on the 'REBOOT RECOVERY' button. The phone will reboot into the recovery environment automatically.
Firmware via TWRP
Before flashing, you need to delete all user data from the phone, this will avoid many problems. press 'WIPE' on the home screen.
Everything is ready to start flashing. Press the 'Install' button.
The file selection screen is displayed. At the very top is the 'Storage' button, which allows you to switch between types of memory.
Select the storage to which the files were copied.
Find the file we need and click on it. A screen opens with a warning about possible negative consequences, you need to check the item 'Zip signature verification', which will avoid using corrupted files when writing to the phone's memory sections.
The procedure for flashing the phone will begin, accompanied by the appearance of inscriptions in the log field and the movement of the progress bar.
The completion of the installation procedure is indicated by the inscription 'Successful'.
Summary: OS: Android 10; Processor: Unisoc SC9863A; Processor clock: 1.40 GHz; Number of cores: 8; GPU: IMG8322; RAM: 3 GB; Internal memory: 32 GB; Memory cards: yes; microSD, microSDHC, microSDXC (up to 128 GB); Display: Color / IPS TFT; 16M colors, 60 Hz; 720 x 1560 px (6.08") 283 ppi; 80.1% screen-to-body ratio; Display protection: yes; Photo matrix: 12 Mpx; Flash: yes LED; Digital zoom: yes; Video formats: H.264, H.265, MPEG4 - 30 fps; Additional: AF; Photo matrix: 5 Mpx; Flash: yes; Digital zoom: yes; Additional: FF; A-GPS: yes; GPS module: yes; Bluetooth: yes v4.2; EDGE: yes; GPRS: yes; IrDA: yes; NFC: yes; USB: yes v2.0 OTG; WAP: yes v2.0; WiFi: yes v802.11 b/g/n; WiFi frequencies: 2.4 GHz; H ...
