MSI P41-C33 specs
Motherboards Specs >> MSI >> MSI P41-C33| Specifications | | | Reviews |
Processor MSI P41-C33
Socket:
LGA775
Processors supported:
Intel Core 2 Quad/Core 2 Duo
System bus:
800 MHz 1333 MHz
Support for multi-core processors:
yes
Chipset MSI P41-C33
Chipset:
Intel G41
SLI/CrossFire:
Scalable Link Interface
Scalable Link Interfaceno
Memory MSI P41-C33
Memory:
DDR3 DIMM 800 - 1333 MHz
Number of memory slots:
2
Supports dual channel mode:
yes
Maximum memory:
8 GB
Disk controllers MSI P41-C33
IDE:Integrated Drive Electronics
Integrated Drive Electronicsnumber of slots: 1, UltraDMA 100
SATA:Serial Advanced Technology Attachment
Serial Advanced Technology Attachmentnumber of connectors SATA 3Gb/s: 4, RAID: no
Expansion slots MSI P41-C33
Expansion slots:
1xPCI-E x16, 2xPCI-E x1, 3xPCI
Audio/video MSI P41-C33
Sound:
7.1CH, HDA, based on the Realtek ALC889/ALC888S
Network MSI P41-C33
Ethernet:
1000 Mbps, based on the Realtek 8111DL
Connection MSI P41-C33
Interfaces:
8 USB, S/PDIF output, 2xCOM, Ethernet, PS/2 (keyboard), PS/2 (mouse), LPT
Back panel connectors:
4 USB, 1xCOM, Ethernet, PS/2 (keyboard), PS/2 (mouse)
Main power connector:
24-pin
Processor power connector:
4-pin
Advanced settings MSI P41-C33
Form factor:
ATX
