MSI P31-Neo2 specs
Motherboards Specs >> MSI >> MSI P31-Neo2| Specifications | | | Reviews |
Processor MSI P31-Neo2
Socket:
LGA775
Processors supported:
Intel Core 2 Quad/Core 2 Duo/Core 2 Extreme/Yorkfield/Wolfdale/Celeron Dual Core/Celeron 400 series/Celeron D/Pentium Dual Core/Pentium 4/Pentium 4 Extreme/Pentium Extreme/Pentium D
System bus:
800 MHz 1333 MHz
Support Hyper-Threading Technology:
yes
Support for multi-core processors:
yes
Chipset MSI P31-Neo2
Chipset:
Intel P31 Express
BIOS:
AMI
SLI/CrossFire:
Scalable Link Interface
Scalable Link Interfaceno
Memory MSI P31-Neo2
Memory:
DDR2 DIMM 667 - 800 MHz
Number of memory slots:
4
Supports dual channel mode:
yes
Maximum memory:
4 GB
Disk controllers MSI P31-Neo2
IDE:Integrated Drive Electronics
Integrated Drive Electronicsnumber of slots: 1, UltraDMA 100
SATA:Serial Advanced Technology Attachment
Serial Advanced Technology Attachmentnumber of connectors SATA 3Gb/s: 4, RAID: 0, 1, 5, 10 based on the Intel ICH7R
Expansion slots MSI P31-Neo2
Expansion slots:
1xPCI-E x16, 2xPCI-E x1, 3xPCI
Audio/video MSI P31-Neo2
Sound:
7.1CH, HDA, based on the Realtek ALC888
Network MSI P31-Neo2
Ethernet:
1000 Mbps, based on the Realtek 8111B/8111C
Connection MSI P31-Neo2
Interfaces:
8 USB, S/PDIF output, 1xCOM, Ethernet, PS/2 (keyboard), PS/2 (mouse), LPT
Back panel connectors:
4 USB, 1xCOM, Ethernet, PS/2 (keyboard), PS/2 (mouse), LPT
Main power connector:
24-pin
Processor power connector:
4-pin
Advanced settings MSI P31-Neo2
Form factor:
ATX
Packing list:
1 SATA cable, 1 cable, 1 plug the rear ports corps
Additional information:
Optional IEEE1394, Lan 10/100/1000 Fast Ethernet .
