MSI MPG X870E CARBON WIFI AM5 ATX X870ECARBONWIFI7 specs
Motherboards Specs >> MSI >> MSI MPG X870E CARBON WIFI AM5 ATX X870ECARBONWIFI7| Specifications | | | Reviews |
General Specs MSI MPG X870E CARBON WIFI AM5 ATX Motherboard X870ECARBONWIFI7
Chipset:
AMD X870E
CPU Socket:
AM5
Memory Slots:
4x 288-Pin
Memory Support:
DDR5 2400, 3200, 4200, 4700 MT/s
Storage Slots:
2x M.2 (M Key) 2260, 2280 (PCIe 5.0 x4)
1x M.2 (M Key) 2260, 2280 (PCIe 4.0 x4)
1x M.2 (M Key) 2280, 22110 (PCIe 4.0 x4)
1x M.2 (M Key) 2260, 2280 (PCIe 4.0 x4)
1x M.2 (M Key) 2280, 22110 (PCIe 4.0 x4)
Expansion Slots:
1x PCIe 5.0 x16
1x PCIe 5.0 x16 (x4 mode)
1x PCIe 4.0 x16 (x4 mode)
1x PCIe 5.0 x16 (x4 mode)
1x PCIe 4.0 x16 (x4 mode)
Wi-Fi:
Wi-Fi 7 (802.11be); Tri-Band (2.4, 5, & 6 GHz) with MU-MIMO Support
Form Factor:
ATX
CPU MSI MPG X870E CARBON WIFI AM5 ATX Motherboard X870ECARBONWIFI7
Chipset:
AMD X870E
CPU Socket:
AM5
Back Panel I/O MSI MPG X870E CARBON WIFI AM5 ATX Motherboard X870ECARBONWIFI7
USB:
Universal Serial Bus
Universal Serial Bus2x USB-C (USB4)
2x USB-C (USB 3.1/3.2 Gen 2)
9x USB-A (USB 3.1/3.2 Gen 2)
2x USB-C (USB 3.1/3.2 Gen 2)
9x USB-A (USB 3.1/3.2 Gen 2)
Thunderbolt:
No
Display:
1x HDMI 2.1
Audio:
2x 1/8" / 3.5 mm
1x S/PDIF
1x S/PDIF
Ethernet / Controller:
1x Realtek 8126 5GbE
1x Realtek 8125 2.5Gigabit
1x Realtek 8125 2.5Gigabit
Wi-Fi Antenna:
2x Connector
Buttons:
BIOS Flashback, Clear CMOS
Memory MSI MPG X870E CARBON WIFI AM5 ATX Motherboard X870ECARBONWIFI7
Memory Slots:
4x 288-Pin
Memory Support:
DDR5 2400, 3200, 4200, 4700 MT/s
Maximum Capacity:
256 GB
Channel Architecture:
Dual Channel
ECC Support:
Non-ECC Unbuffered
Storage Expansion MSI MPG X870E CARBON WIFI AM5 ATX Motherboard X870ECARBONWIFI7
SATA:Serial Advanced Technology Attachment
Serial Advanced Technology Attachment4x SATA III
Storage Slots:
2x M.2 (M Key) 2260, 2280 (PCIe 5.0 x4)
1x M.2 (M Key) 2260, 2280 (PCIe 4.0 x4)
1x M.2 (M Key) 2280, 22110 (PCIe 4.0 x4)
1x M.2 (M Key) 2260, 2280 (PCIe 4.0 x4)
1x M.2 (M Key) 2280, 22110 (PCIe 4.0 x4)
Optane Memory Support:
No
RAID Support:
RAID 0, 1, 10
Internal I/O MSI MPG X870E CARBON WIFI AM5 ATX Motherboard X870ECARBONWIFI7
Expansion Slots:
1x PCIe 5.0 x16
1x PCIe 5.0 x16 (x4 mode)
1x PCIe 4.0 x16 (x4 mode)
1x PCIe 5.0 x16 (x4 mode)
1x PCIe 4.0 x16 (x4 mode)
USB:Universal Serial Bus
Universal Serial Bus1x USB 3.2 Gen 2x2 Header (Supports 1 USB-C Port)
2x USB 3.0 / 3.1/3.2 Gen 1 Header (Supports 4 USB-A Port)
2x USB 2.0 Header (Supports 4 USB-A Port)
2x USB 3.0 / 3.1/3.2 Gen 1 Header (Supports 4 USB-A Port)
2x USB 2.0 Header (Supports 4 USB-A Port)
Air Cooling:
1x 4-Pin CPU
5x 4-Pin System
5x 4-Pin System
Liquid Cooling:
1x 4-Pin Pump
Power Connectors:
1x 24-Pin Mainboard
2x 8-Pin CPU
1x 8-Pin ATX
2x 8-Pin CPU
1x 8-Pin ATX
Security:
Chassis Intrusion
LED Header:
4x RGB
Audio:
1x Speaker
Diagnostics:
2-Digit Debug LED, Clear CMOS, Flash BIOS
BIOS MSI MPG X870E CARBON WIFI AM5 ATX Motherboard X870ECARBONWIFI7
ROM:
256 Mb
Front Panel I/O MSI MPG X870E CARBON WIFI AM5 ATX Motherboard X870ECARBONWIFI7
Front Panel I/O:
AAFP, USB 3.0 / 3.1/3.2 Gen 1, USB 3.2 Gen 2x2
Audio MSI MPG X870E CARBON WIFI AM5 ATX Motherboard X870ECARBONWIFI7
Audio Codec:
Realtek ALC4080 (7.1-Channel)
DAC:
No
Wireless MSI MPG X870E CARBON WIFI AM5 ATX Motherboard X870ECARBONWIFI7
Wi-Fi:
Wi-Fi 7 (802.11be); Tri-Band (2.4, 5, & 6 GHz) with MU-MIMO Support
Bluetooth:
5.4
Module Support:
1 E Key M.2
Software MSI MPG X870E CARBON WIFI AM5 ATX Motherboard X870ECARBONWIFI7
OS Compatibility:
Windows 11 (64-Bit Only)
Physical MSI MPG X870E CARBON WIFI AM5 ATX Motherboard X870ECARBONWIFI7
Form Factor:
ATX
Dimensions:
12.0 x 9.60" / 304.8 x 243.84 mm
