MSI MPG X670E CARBON WIFI AM5 ATX specs
Motherboards Specs >> MSI >> MSI MPG X670E CARBON WIFI AM5 ATX| Specifications | | | Reviews |
Motherboard Details MSI MPG X670E CARBON WIFI AM5 ATX
Chipset:
AMD X670
CPU Socket:
AM5
Memory MSI MPG X670E CARBON WIFI AM5 ATX
Maximum Capacity:
128 GB
Memory Slots:
4 x 288-Pin
Memory Support:
DDR5 MHz
Storage MSI MPG X670E CARBON WIFI AM5 ATX
M.2:
2 x 2260, 2280 (PCIe 5.0 x4)
1 x 2260, 2280, 22110 (PCIe 4.0 x4)
1 x 2260, 2280 (PCIe 4.0 x4)
1 x 2260, 2280, 22110 (PCIe 4.0 x4)
1 x 2260, 2280 (PCIe 4.0 x4)
RAID Support:
RAID 0, 1, 10 (SATA)
RAID 0, 1, 10 (SATA)
RAID 0, 1, 10 (SATA)
SATA:
Serial Advanced Technology Attachment
Serial Advanced Technology Attachment6 x SATA III
Optane Memory Support:
No
Internal I/O Connectors MSI MPG X670E CARBON WIFI AM5 ATX
Air Cooling:
1 x 4-Pin CPU
5 x 4-Pin System
1 x Thermal Sensor
5 x 4-Pin System
1 x Thermal Sensor
Audio:
4 x 1/8" / 3.5 mm
1 x S/PDIF
1 x S/PDIF
Audio:
1 x Speaker
Buttons:
BIOS Flashback, Clear CMOS
Diagnostics:
2-Digit Debug LED, Clear CMOS, Flash BIOS
Display:
1 x DisplayPort
1 x HDMI
1 x HDMI
Ethernet / Controller:
1 x Realtek RTL8125BG 2.5Gigabit
Expansion Slots:
1 x PCIe 5.0 x16 (x16 mode)
1 x PCIe 5.0 x16 (x8 mode)
1 x PCIe 4.0 x16 (x4 mode)
1 x PCIe 5.0 x16 (x8 mode)
1 x PCIe 4.0 x16 (x4 mode)
Front Panel I/O:
AAFP, USB 3.0 / 3.1/3.2 Gen 1, USB 3.1/3.2 Gen 2
LED Header:
3 x RGB
Liquid Cooling:
1 x 4-Pin Pump
Multi-GPU Support:
AMD CrossFireX
Power Connectors:
1 x 24-Pin Mainboard
2 x 8-Pin CPU
2 x 8-Pin CPU
Security:
Chassis Intrusion
Thunderbolt:
None
USB:Universal Serial Bus
Universal Serial Bus2 x USB-A (USB 2.0)
6 x USB-A (USB 3.1/3.2 Gen 2)
1 x USB-C (USB 3.1/3.2 Gen 2)
1 x USB-C (USB 3.2 Gen 2x2)
6 x USB-A (USB 3.1/3.2 Gen 2)
1 x USB-C (USB 3.1/3.2 Gen 2)
1 x USB-C (USB 3.2 Gen 2x2)
USB:Universal Serial Bus
Universal Serial Bus2 x 2.0 Header (Supports 4 USB-A Port)
2 x 3.0 / 3.1/3.2 Gen 1 Header (Supports 4 USB-A Port)
1 x 3.1/3.2 Gen 2 Header (Supports 1 USB-C Port)
2 x 3.0 / 3.1/3.2 Gen 1 Header (Supports 4 USB-A Port)
1 x 3.1/3.2 Gen 2 Header (Supports 1 USB-C Port)
Wi-Fi Antenna:
2 x Connector
Audio MSI MPG X670E CARBON WIFI AM5 ATX
Audio Codec:
Realtek ALC4080 (7.1-Channel)
Wireless MSI MPG X670E CARBON WIFI AM5 ATX
Bluetooth:
5.2
Wi-Fi:
Wi-Fi 6E (802.11ax)
Dimensions MSI MPG X670E CARBON WIFI AM5 ATX
Dimensions:
9.60 x 12.0" / 243.84 x 304.8 mm
Form Factor:
ATX
