Biostar NF61S-M2 TE specs
Motherboards Specs >> Biostar >> Biostar NF61S-M2 TE| Specifications | | | Reviews |
Processor Biostar NF61S-M2 TE
Socket:
AM2
Processors supported:
AMD Athlon 64 X2/Athlon X2/Athlon 64 FX/Athlon 64/Sempron
System bus:
HyperTransport
Support for multi-core processors:
yes
Chipset Biostar NF61S-M2 TE
Chipset:
NVIDIA GeForce 6100
BIOS:
Award
SLI/CrossFire:
Scalable Link Interface
Scalable Link Interfaceno
Memory Biostar NF61S-M2 TE
Memory:
DDR2 DIMMs 400 - 800 MHz
Number of memory slots:
2
Supports dual channel mode:
yes
Maximum memory:
4 GB
Disk controllers Biostar NF61S-M2 TE
IDE:Integrated Drive Electronics
Integrated Drive Electronicsnumber of slots: 1, UltraDMA 133
SATA:Serial Advanced Technology Attachment
Serial Advanced Technology Attachmentnumber of connectors SATA 3Gb/s: 2, RAID 0, 1
Expansion slots Biostar NF61S-M2 TE
Expansion slots:
1xPCI-E x16, 1xPCI-E x1, 2xPCI
Audio/video Biostar NF61S-M2 TE
Sound:
5.1CH, HDA, based on the Realtek ALC662
Integrated video:
yes, based on the NVIDIA GeForce 6100
Network Biostar NF61S-M2 TE
Ethernet:
10/100 Mbit/s, based on the Realtek RTL8201CL
Connection Biostar NF61S-M2 TE
Interfaces:
8 USB, S/PDIF output, 1xCOM, D-Sub, Ethernet, PS/2 (keyboard), PS/2 (mouse), LPT
Back panel connectors:
4 USB, 1xCOM, D-Sub, Ethernet, PS/2 (keyboard), PS/2 (mouse), LPT
Main power connector:
24-pin
Processor power connector:
4-pin
Advanced settings Biostar NF61S-M2 TE
Form factor:
microATX
Packing list:
1 IDE cable, 1 SATA cable, 1 plug the rear ports corps
