ASRock Z590 Pro4 90-MXBEJ0-A0UAYZ specs
Motherboards Specs >> ASRock >> ASRock Z590 Pro4 90-MXBEJ0-A0UAYZ| Specifications | | | Reviews | | | Compare |
Back panel I/O ports ASRock Z590 Pro4 90-MXBEJ0-A0UAYZ
DisplayPort version:
1.4
DisplayPorts quantity:
1
HDMI ports quantity:
1
PS/2 ports quantity:
1
Ethernet LAN (RJ-45) ports:
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:
2
USB 2.0 ports quantity:
2
BIOS ASRock Z590 Pro4 90-MXBEJ0-A0UAYZ
System Management BIOS (SMBIOS) version:
2.7
ACPI version:
6.0
BIOS type:
UEFI AMI
Expansion slots ASRock Z590 Pro4 90-MXBEJ0-A0UAYZ
Number of M.2 (M) slots:
1
PCI Express x16 (Gen 3.x) slots:
1
PCI Express x16 (Gen 4.x) slots:
1
PCI Express x1 (Gen 3.x) slots:
3
Features ASRock Z590 Pro4 90-MXBEJ0-A0UAYZ
Windows operating systems supported:
Windows 10 x64
Audio output channels:
7.1 channels
Motherboard chipset:
Intel Z590
Motherboard chipset family:
Intel
Motherboard form factor:
ATX
Component for:
PC
Internal I/O ASRock Z590 Pro4 90-MXBEJ0-A0UAYZ
RGB LED pin header:
Yes
12V power connector:
Yes
Thunderbolt headers:
1
TPM connector:
Yes
EPS power connector (8-pin):
Yes
CPU fan connector:
Yes
ATX Power connector (24-pin):
Yes
Front panel audio connector:
Yes
Number of SATA III connectors:
6
USB 3.2 Gen 2 (3.1 Gen 2) connectors:
1
USB 3.2 Gen 1 (3.1 Gen 1) connectors:
2
USB 2.0 connectors:
2
Memory ASRock Z590 Pro4 90-MXBEJ0-A0UAYZ
Unbuffered memory:
Yes
Maximum internal memory:
128 GB
Supported memory clock speeds:
4600, 4800 MHz
Non-ECC:
Yes
Memory channels:
Dual-channel
Memory slots type:
DIMM
Number of memory slots:
4
Supported memory types:
DDR4-SDRAM
Network ASRock Z590 Pro4 90-MXBEJ0-A0UAYZ
Wi-Fi:
No
Wake-on-LAN ready:
Yes
LAN controller:
Dragon RTL8125BG
Ethernet interface type:
2.5 Gigabit Ethernet
Ethernet LAN:
Yes
Networking ASRock Z590 Pro4 90-MXBEJ0-A0UAYZ
Wi-Fi:
No
Wake-on-LAN ready:
Yes
LAN controller:
Dragon RTL8125BG
Ethernet interface type:
2.5 Gigabit Ethernet
Ethernet LAN:
Yes
Packaging content ASRock Z590 Pro4 90-MXBEJ0-A0UAYZ
Drivers included:
Yes
Cables included:
SATA
Processor ASRock Z590 Pro4 90-MXBEJ0-A0UAYZ
Compatible processor series:
Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium®
Processor socket:
LGA 1200
Processor manufacturer:
Intel
Rear panel I/O ports ASRock Z590 Pro4 90-MXBEJ0-A0UAYZ
DisplayPort version:
1.4
DisplayPorts quantity:
1
HDMI ports quantity:
1
PS/2 ports quantity:
1
Ethernet LAN (RJ-45) ports:
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:
2
USB 2.0 ports quantity:
2
Storage controllers ASRock Z590 Pro4 90-MXBEJ0-A0UAYZ
Supported storage drive interfaces:
M.2, SATA III
Weight & dimensions ASRock Z590 Pro4 90-MXBEJ0-A0UAYZ
Depth:
244 mm
Width:
305 mm
