Lenovo ThinkVision 23.8" Video Conferencing IPS 63D8MAR3US specs.
Monitors Specs >> Lenovo >> Lenovo ThinkVision 23.8" Video Conferencing IPS 63D8MAR3US| Specifications | | | Reviews |
General Specs Lenovo ThinkVision 23.8" Video Conferencing IPS Monitor 63D8MAR3US
Display Size:
This diagonal display size is usually measured in inches.
This diagonal display size is usually measured in inches.23.8"
Panel Type:
IPS-Type LCD
Native Resolution:
1920 x 1080
Maximum Brightness:
250 nits / cd/m2 (Peak in SDR Mode)
HDR Support:
No
Color Support:
16.7 Million Colors (6-Bit+FRC)
Color Gamut:
99% sRGB
Finish:
Anti-Glare / Matte
Touchscreen Technology:
No
Inputs:
Rear:
1x HDMI 1.4
1x DisplayPort 1.2
1x DE-15/DB-15
1x HDMI 1.4
1x DisplayPort 1.2
1x DE-15/DB-15
Outputs:
Rear:
1x 1/8" / 3.5 mm
1x 1/8" / 3.5 mm
USB I/O:
Rear:
1x USB-B 3.0 / 3.1/3.2 Gen 1
3x USB-A 3.0 / 3.1/3.2 Gen 1
1x USB-A 2.0
1x USB-B 3.0 / 3.1/3.2 Gen 1
3x USB-A 3.0 / 3.1/3.2 Gen 1
1x USB-A 2.0
Built-In Speakers:
Yes, 2x 3 W
Webcam:
User-Facing: 2 MP (1080p)
Display Lenovo ThinkVision 23.8" Video Conferencing IPS Monitor 63D8MAR3US
Display Size:This diagonal display size is usually measured in inches.
This diagonal display size is usually measured in inches.23.8"
Panel Type:
IPS-Type LCD
Aspect Ratio:
16:9
Native Resolution:
1920 x 1080
Maximum Brightness:
250 nits / cd/m2 (Peak in SDR Mode)
HDR Support:
No
Contrast Ratio:
1000:1
Dynamic Contrast Ratio:
3,000,000:1
Response Time:
4 ms
Refresh Rate:
75 Hz
Variable Refresh Technology:
No
Color Support:
16.7 Million Colors (6-Bit+FRC)
Color Gamut:
99% sRGB
Viewing Angle (H x V):
178 x 178°
Pixels Per Inch (ppi):
93 ppi
Finish:
Anti-Glare / Matte
Touchscreen Technology:
No
Connectivity Lenovo ThinkVision 23.8" Video Conferencing IPS Monitor 63D8MAR3US
Inputs:
Rear:
1x HDMI 1.4
1x DisplayPort 1.2
1x DE-15/DB-15
1x HDMI 1.4
1x DisplayPort 1.2
1x DE-15/DB-15
Outputs:
Rear:
1x 1/8" / 3.5 mm
1x 1/8" / 3.5 mm
HDCP Support:
No
USB I/O:
Rear:
1x USB-B 3.0 / 3.1/3.2 Gen 1
3x USB-A 3.0 / 3.1/3.2 Gen 1
1x USB-A 2.0
1x USB-B 3.0 / 3.1/3.2 Gen 1
3x USB-A 3.0 / 3.1/3.2 Gen 1
1x USB-A 2.0
USB Power Delivery:
Yes
Multi-Input Support (PIP/PBP):
No
Speaker Lenovo ThinkVision 23.8" Video Conferencing IPS Monitor 63D8MAR3US
Built-In Speakers:
Yes, 2x 3 W
Built-In Mic:
Yes
Webcam:
User-Facing: 2 MP (1080p)
Electrical Lenovo ThinkVision 23.8" Video Conferencing IPS Monitor 63D8MAR3US
Power Consumption:
Typical: 18.0 W
Maximum: 60.0 W
Maximum: 60.0 W
Input Power:
100 to 240 VAC, 50 / 60 Hz
Power Adapter Type:
Internal
General Lenovo ThinkVision 23.8" Video Conferencing IPS Monitor 63D8MAR3US
Operating Conditions:
32 to 104°F / 0 to 40°C at 10 to 80% Humidity
Storage Conditions:
-20 to 60°F / -28 to 15°C at 5 to 95% Humidity
Certifications:
ENERGY STAR, EPEAT Gold, RoHS, TCO Certified 9.0, TUV Rheinland Eye Comfort
Adjustments:
Height: 6.1" / 155 mm
Tilt: 28° (-5 to 23.5°)
Rotation
Swivel: 90° (-45 to 45°)
Tilt: 28° (-5 to 23.5°)
Rotation
Swivel: 90° (-45 to 45°)
Mounting-Hole Pattern:
100 x 100 mm
Lock Slot:
Yes, Kensington
Dimensions:
21.2 x 15.2 x 7.8" / 53.8 x 38.6 x 19.8 cm (with Stand)
21.2 x 14.3 x 2.1" / 53.8 x 36.3 x 5.3 cm (without Stand)
21.2 x 14.3 x 2.1" / 53.8 x 36.3 x 5.3 cm (without Stand)
Weight:
13.2 lb / 6.0 kg (with Stand)
8.8 lb / 4.0 kg (without Stand)
8.8 lb / 4.0 kg (without Stand)
