Lenovo Legion Y540-15IRH 81SX 81SX0005US specs.

  Laptops Specs >> Lenovo >> Lenovo Legion Y540-15IRH 81SX 81SX0005US

Specifications | Reviews | Useful keys
Screenshot


Lenovo Legion Y540-15IRH 81SX 81SX0005US




Basic Specs Lenovo Legion Y540-15IRH 81SX 81SX0005US

Notebook Type:
Notebook
OS:
Windows 10 Pro, Windows 10 Pro 64-bit Edition
Language:
English

Processor Lenovo Legion Y540-15IRH 81SX 81SX0005US

Manufacturer:
Intel
Processor:
Core i7
Processor Number:
I7-9750H
Generation:
9
Clock Speed:
2.6 GHZ
64-bit Computing:
Yes
Number of Cores:
6-core
Max Turbo Speed:
4.5 GHZ

Cache Memory Lenovo Legion Y540-15IRH 81SX 81SX0005US

Installed Size:
12 megabyte

RAM Lenovo Legion Y540-15IRH 81SX 81SX0005US

Size:
16 GB
Form Factor:
SO-DIMM 260-pin
Technology:
DDR4 SDRAM
Max Supported Size:
32 GB
Memory Speed:
2666 megahertz
Slots Qty:
2

Display & Graphics Lenovo Legion Y540-15IRH 81SX 81SX0005US

Diagonal Size:
15.6 inch
Resolution:
1920 x 1080
Display Resolution Abbreviation:
Full HD
Type:
LED
Monitor Features:
72% color gamut, Anti-glare
Image Aspect Ratio:
16:9
LCD Backlight Technology:
LED backlight
Image Brightness:
300 candela per square metre
TFT Technology:
IPS
Widescreen Display:
Yes
Graphics Memory Capacity:
6 GB
Graphics Memory Technology:
GDDR6 SDRAM

Hard Drive Lenovo Legion Y540-15IRH 81SX 81SX0005US

Capacity:
512 GB
Type:
SSD
SSD Form Factor:
M.2
Interface:
PCIe
Hard Drive Features:
NVM Express (NVMe)

Hard Drive (2) Lenovo Legion Y540-15IRH 81SX 81SX0005US

Capacity:
1 TB
Type:
HDD
Interface:
Serial ATA-600
Spindle Speed:
7200 revolutions per minute

Optical Storage Lenovo Legion Y540-15IRH 81SX 81SX0005US

Type:
None
Drive Type:
No optical drive

Digital Camera Lenovo Legion Y540-15IRH 81SX 81SX0005US

Resolution (MP):
1 Megapixel
Resolution:
720p
Webcam Capability:
Yes
Features:
Privacy shutter

Video Output Lenovo Legion Y540-15IRH 81SX 81SX0005US

Discrete Graphics Processor:
Yes
Graphics Processor:
NVIDIA GeForce GTX 1660 Ti, NVIDIA GeForce GTX 1660 Ti / Intel UHD Graphics 630
Graphics Processor Series:
NVIDIA GeForce GTX, Intel UHD Graphics
Multi-GPU Configuration:
1 single GPU card / integrated GPU
VR Ready:
Yes

Input Device Lenovo Legion Y540-15IRH 81SX 81SX0005US

Type:
Touchpad, Keyboard
Numeric Keypad:
Yes
Backlight:
Yes
Features:
Multi-touch touchpad, White LED backlight

Audio Output Lenovo Legion Y540-15IRH 81SX 81SX0005US

Type:
Stereo speakers
Audio Codec:
Realtek ALC3287
Compliant Standards:
High Definition Audio, Dolby Atmos
Features:
Harman audio technology

Keyboard Lenovo Legion Y540-15IRH 81SX 81SX0005US

Keyboard Localization:
US
Keyboard Layout:
QWERTY

Interfaces Lenovo Legion Y540-15IRH 81SX 81SX0005US

USB 3.0 Ports Qty:
3
USB-C Ports Qty:
1
Interfaces:
2 x USB 3.1 Gen 1, Headphone/microphone combo jack, USB 3.1 Gen 1 (Always On), Mini DisplayPort, USB-C 3.1 Gen 1/DisplayPort 1.2, LAN, HDMI

Networking Lenovo Legion Y540-15IRH 81SX 81SX0005US

Wireless Protocol:
802.11ac, Bluetooth 4.1
Data Link Protocol:
IEEE 802.11ac, Bluetooth 4.1, Ethernet, Fast Ethernet, Gigabit Ethernet
Interface (Bus) Type:
M.2 Card
Wired Protocol:
Gigabit Ethernet

Miscellaneous Lenovo Legion Y540-15IRH 81SX 81SX0005US

Audio Input:
Dual array microphone
Compliant Standards:
Energy-Related Products (ErP) Lot 3, RoHS
Included Accessories:
Power adapter
Theft/Intrusion Protection:
Security lock slot (cable lock sold separately)
Security Slot Type:
Kensington security slot
Features:
LED lighting, Power-on password, Hard drive password

Design Lenovo Legion Y540-15IRH 81SX 81SX0005US

Depth:
26.7 centimetre
Height:
2.59 centimetre
Weight:
2.3 keg
Width:
36 centimetre
Case Material:
Polycarbonate ABS
Color:
Raven black

Battery Information Lenovo Legion Y540-15IRH 81SX 81SX0005US

Capacity:
57 watt hour(s)
Technology:
Lithium ion
Cells:
3-cell
Run Time (Up To):
5 Hours, 10 Hours

Power Device Lenovo Legion Y540-15IRH 81SX 81SX0005US

Frequency Required:
50/60 hertz
Nominal Voltage:
AC 120/230 V
Power Provided:
230 watt





Reviews, Questions about Lenovo Legion Y540-15IRH 81SX 81SX0005US


DCWDecember 31, 2022
How many memory slots does this laptop have?



Write Review / Ask a question about Lenovo Legion Y540-15IRH 81SX 81SX0005US
